TT-WSM-01 Rotary Single Lane Multi-Weight Sorting Machine

TT-WSM-01 Rotary Single Lane Multi-Weight Sorting Machine

Description

weight sorting machine
无标题文档

Automatic 304 Stainless Steel Weight Grading Machine Suitable for fruit

weight sorting machine weight sorting machine weight sorting machine weight sorting machine

1. Highly Efficient and Economic.
Multi-sorting and automatic weight checking for labor cost saving and efficiency improving.

2. Easy.
Large LCD touch screen display. Chinese and English interface, Language customized is available. HMI program design can accomplish weight sorting with wide range of products.

3. Precision./High Speed.
High-precision load cell ensure high detection accuracy. Speed can be adjustable as per requirements by frequency conversion control motor.

4. Real Time.
The graph shows the statistical distribution of the sorting results and grasps the sorting dynamics in real time.

5. Memory.
100 kinds of product sorting parameters can be preset, and different products parameters can be quickly switched.

6.Centralized Control.
One PC / HMI can control multiple sorting machines.

7. Customization.
Weight sorting grades can be customized according to customer's requirement.

8. Data.
Preset data transmission interface which can set or export product sorting parameters via USB. Data can be stored one year by USB.

9.Zero Tracking. / Intelligent.
Manual or automatic reset as well as dynamic zero tracking.The weight value can be corrected automatically.

10. Sturdy Structure.
This machine has good performance and is hygienic for its solid Stainless steel 304 structure.

11. Connection.
Interface can be connected with PC or other smart communication tools.

weight sorting mahine
ModelTT-WSM
Max.Weighing(one time)500g
Rate power1.0KW
Accuracy Range±5g to ±3g
Min. Scale Value0.1g
Conveying Speed30m/min
Max. Speed250BMP(Depends on manual feeding speed)
Material Available Size≤170mm(L)*85mm(W)*45mm(H)
Rejecting MethodOverturned device
Control SystemHigh Speed A/D Sampling Module
Preset Product Number60
Power AC220V±10% 50Hz/60Hz,0.6kW
Machine Dimension3620mm(L)*700mm(W)*1520mm(H)
Air Compressor Requirement0.6-1Mpa
Air Pressure InterfaceΦ12mm, Φ6mm
The Working EnvironmentTemperature:0ºC~40ºC;Humidity:30%~95%
Machine Frame MaterialStainless steel304/POM
PackageWooden case packing


weight sorting machine weight sorting machine

Applicable for multi-weight sorting of marine as well as agricultural products,such as trepang, abalone, shark fin, hippocampus, jellyfish, dried octopusand squid, fish maw, etc. as well as fruits, vegetables, melons, nuts, spices,pastries, frozen food, ham, etc.

weight sorting machine

check weigher X Ray Inspection

Toptic Tech (Zhongshan) Co.,Ltd. is one of subsidiary company of Guangdong Toupack Intelligent Equipment Co., Ltd. was established in 2009, located in the National Torch High-tech Development Zone, Zhongshan City, Guangdong Province. It is a high-tech enterprise. The company focuses on the R&D and production of intelligent weighing, packaging, testing, and conveying systems. The products are exported to more than 80 countries and regions at home and abroad. It has an overseas after-sales service center
in California, USA; it has a wholly-owned subsidiary-Anhui Toupack Intelligent Equipment Co., Ltd. in East China, and has offices in Shanghai and Chengdu, Sichuan.

·Our factory covers an area of 17,300 sqm. QC team consists of 10 people.

· Pre-sales Services:
a.Collecting customer’s product information and requirements.
b.Providing initial solution and offer for customer's opinions within 6 Hours against information collection.
c.Sufficient applications and videos help customers to get a
better understanding of our equipment.

· In-sales Services:
a.Sending the drawings of ordered machines for customer's approval before production.
b.Following up each production process to guarantee on-time delivery.
c.Sharing the machine running test and inspection video for customer's confirmation
before delivery.
d.Collaborating with shipping agents for freight arrangement and keeping customers updated on ETD & ETA info.

· After-sales Service:
Operation manuals / Videos for machine installation, setting,
adjusting and/or maintenance are available for end users.

· Online After-sales Service:
An in-time response within 4 hours in case of machine
error,supportive advice shall be offered within 24 hours via whatsapp, wechat, and
other social network apps. Our engineer team can communicate in English for high
efficient solution.

· Onsite After-sales Service:
Engineer(s) are available for on-spot technical support at end users' factories if necessary.

check weigher

1.What industries is this kind of sorting machine applied in?
Circular Multi-weight sorting machine suitable for marine and agricultural industry.

2.What material is suitable for circular multi-weight sorting machine?
Circular Multi-weight sorting machine suitable for chicken legs / wings / meat, trepang, abalone, small fish, shrimp, Chinese medical herbs, fruits and many other products with the size within 12*18CM and the weight within 500g(1~14 grade sorting), regardless of their shape.

3. What are your Payment terms?
T/T

4. How can we choose the machinery?
Contact with our sales, and provide products and requirement, we will give you solution with suitable machine and offer accordingly.

5. When can we expect the goods to be delivered?
Regular machine can be delivered within 20-25 days. For customized machines, need evaluate depend on the project.

6. How about the after-sales service?
We have a perfect after-sales service system and promise to respond within 24 hours. Online service is free on anytime. If cannot solve by online, on-site after service is also available.

Warranty: 1 year

7. How to cooperate with you?
All you need to do is contact our sales representatives who will patiently guide you through the whole process.

We solemnly promise: equipment and material contact parts are 304 stainless steel material or food grade plastic, in line with the health requirements.
